Thermal Imager Temperature Sensor AMG8833
Price
৳4,800
/Per piece
Share
Top Selling Products
IR 8x8 Thermal Imager Temperature Sensor Module For Arduino Raspberry Pi. Power supply: 3-5v Panasonic's thermal imaging camera sensor is an 8x8 infrared thermal sensor array. When connected to your microcontroller (or Raspberry Pi), it will return a set of 64 separate infrared temperature readings via I2C. It's like a fancy camera, but it's compact and simple, and easy to integrate. The is Panasonic's next-generation 8x8 thermal infrared sensor and offers higher performance than the previous . The sensor only supports I2C and has a configurable interrupt pin that can be triggered when any single pixel is above or below the threshold you set. The thermal imaging camera measures temperature from 0°C to 80°C (32°F to 176°F). The accuracy is + - 2.5 ° C (4.5 ° F). It can detect humans from distances as far as 7 meters (23) feet. With a maximum frame rate of 10 Hz, it is ideal for creating your own body detector or mini camera. We use this breakthrough code on Arduino or compatible (sensors communicate via I2C) or on Python's Raspberry Pi. On the Pi, with the image processing help of the SciPy python library, we can insert 8x8 meshes and get some very good results! Add heat-vision to your project and with an AMG8833 Grid-EYE Breakout from Tronixlabs Australia! This sensor from is an 8x8 array of IR thermal sensors. When connected to your microcontroller (or raspberry Pi) it will return an array of 64 individual infrared temperature readings over I2C. It's like those fancy thermal cameras, but compact and simple enough for easy integration.This part will measure temperatures ranging from 0°C to 80°C (32°F to 176°F) with an accuracy of +- 2.5°C (4.5°F). It can detect a human from a distance of up to 7 meters (23) feet. With a maximum frame rate of 10Hz, It's perfect for creating your own human detector or mini thermal camera. We have code for using this breakout on an Arduino or compatible (the sensor communicates over I2C) or on a Raspberry Pi with Python. On the Pi, with a bit of image processing help from the SciPy python library we were able to interpolate the 8x8 grid and get some pretty nice results!
The AMG8833 is the next generation of 8x8 thermal IR sensors from , and offers higher performance than it's predecessor the AMG8831. The sensor only supports I2C, and has a configurable interrupt pin that can fire when any individual pixel goes above or below a threshold that you set.
To make it easy to use, we pick & placed it on a breakout board with a 3.3V regulator and level shifting. So you can use it with any 3V or 5V microcontroller or computer.
Even better - Adafruit have done all the hard work here, with example code and supporting software libraries to get you up in running in just a few lines of code! Check out our guide for how to get started.
Technical details:
Check our the detailed guide for wiring diagrams, datasheets, schematics, libraries, code, Fritzing objects, etc!
Product Dimensions: 25.8mm x 25.5mm x 6.0mm / 1.0" x 1.0" x 0.2"
